Application:

Used in hospitals or dental clinics during dental procedures such as tooth drilling to aspirate saliva, blood, and fine particulates from the patient's oral cavity, as well as the mist cloud generated by high-speed turbine dental drills.

Operating Conditions:

1 .Ambient Temperature: 5°C – 40°C;

Relative Humidity: ≤ 70%; Atmospheric Pressure: 86 – 106 kPa;

2 .Power Supply Requirements:

Rated Voltage: AC 220 V ±10%;

Frequency: 50 Hz/60 Hz;

Rated Power: 0.6/0.62 kW;

Rated Current: 3.7 A;

Technical Specifications:

1 .High-flow suction pump:

Motor Speed: ≥ 2800 rpm – capable of instantly generating a high suction flow rate compliant with dental application standards without any waiting time; Maximum vacuum: -12 kPa;

2 .High suction capacity – strong suction: 10 L/min; weak suction: 3 L/min;

3 .Integrated black acrylic panel – wear-resistant and corrosion-resistant;

4 .2000 mL water-air separation tank equipped with a built-in high-sensitivity dual-level sensor for effective protection of the suction pump;

5 .External integrated suction filtration screen for easy cleaning and replacement;

6 .Intelligent control system – activate the suction pump immediately by pressing the strong/weak suction lever;

7 .One-touch wastewater discharge function.

8 .Noise Level: 64 dB;

9 .Product Weight: 30 kg;

10 .Packaging Weight: 35 kg;

11 .Product Dimensions: 37 × 33 × 83 cm;

4.12 Packaging Dimensions: 45 × 43 × 96 cm (carton);

 Configuration List:

Main Unit – 1 unit;

Strong suction tube – 1 piece;

Weak suction tube – 1 piece;

Sputum filtration filter – 1 set;

 Strong/Weak suction handle – 1 set;

Strong suction nozzle – 1 unit;

Weak suction nozzle – 1 unit
