Number of dental chair units:

Suitable for 10 dental chair units.

Equipment Use:

Used as the power source for high-speed turbine dental handpieces and low-speed pneumatic motor handpieces during dental treatment procedures such as tooth drilling.

Operating Conditions:

Environmental Conditions:

1. Ambient temperature: 5°C – 40°C;

2. Relative humidity: ≤ 70%;

3. Atmospheric pressure: 86 – 106 kPa;

4. Ventilation flow rate: ≥ 0.40 m³/s;



Power Supply Conditions:

1. Rated voltage: AC 380 V ±10%;

2. Frequency: 50 Hz;

3. Rated power: 2.2 kW;

4. Noise level: ≤ 82 dB;

5. Air tank capacity: 120 L.



Technical Specifications:

1. V-type 4-cylinder air compressor – Motor speed: ≥ 1400 rpm;

2. Motor power: 2.2 kW;

3. Nominal flow rate: 320 L/min (0.6 MPa);


   4.The air tank is internally coated with high-temperature anti-rust coating;

   3. Starting pressure: 0.5 MPa; Stop pressure: 0.75 MPa;

   4. Integrated design with elegant and professional appearance;

   5. Automatic drainage system;

   6. Product dimensions: 108 cm × 50 cm × 90 cm (main unit);

   7. Gross weight: ≤ 134 kg.
